SB 7500 busbar support

Space-saving flat mounted design
Optimized for switchboard applications
Insulating busbar support mounting
ignoreGeneration#Zoomable Image
ignoreGeneration#Zoomable Image
Price Price Available on Request
Expert Technical Support
Territory-Based Service
Certifications: IEC 61439-1, IEC 60865-1
View Specs

Technical Specifications at a Glance

Detailed technical specifications for the SB 7500 busbar support system

PARAMETER
SPECIFICATION
Section
50x5
Number of Poles
3-4
Rated Voltage
1000 VAC
Busbar Distance
75mm
Mounting Type
Flat Mount
Support Type
Multipolar
Application
Switchboard
Insulation
Yes
Certification
IEC Certified
Country of Origin
🇫🇷 France

Engineered for Performance

Experience the advantages of precision-designed busbar supports for industrial electrical applications

Space-Saving Design

Optimized flat-mounted configuration maximizes available space in switchboard applications where footprint is critical for efficient panel design.

Switchboard Optimized

Specifically engineered for demanding switchboard environments, providing reliable busbar mounting with superior performance in compact installations.

Electrical Insulation

Advanced insulating properties ensure safe busbar mounting on panels while maintaining electrical isolation and preventing short circuits.

IEC Compliance

Meets rigorous IEC 61439-1 and IEC 60865-1 standards ensuring reliable performance and safety in industrial electrical installations.

Easy Installation

Simplified mounting system reduces installation time and complexity while ensuring secure busbar positioning in panel applications.

Precision Engineering

Manufactured to exacting tolerances for consistent performance and reliability in critical electrical distribution systems and control panels.

Frequently Asked Questions

What are the key applications for the SB 7500 busbar support?
The SB 7500 is specifically designed for switchboard applications where space and footprint are critical factors. It provides secure mounting for busbars in compact electrical panel configurations.
What voltage rating does this busbar support handle?
The SB 7500 busbar support is rated for 1000 VAC, making it suitable for high-voltage industrial electrical applications and commercial switchboard installations.
What certifications does the SB 7500 busbar support have?
This product meets IEC 61439-1 and IEC 60865-1 standards, ensuring compliance with international electrical safety and performance requirements for switchboard components.
What is the busbar distance specification for this support?
The SB 7500 is designed with a 75mm busbar distance, accommodating standard spacing requirements for multipolar busbar configurations in switchboard applications.
How many poles does this busbar support accommodate?
The SB 7500 supports 3-4 pole configurations, providing flexibility for various electrical distribution requirements and switchboard design specifications.

Versatile Applications Across Industrial Sectors

The SB 7500 busbar support serves critical switchboard applications where space optimization is essential

Packaging Materials

Switchboard Applications

Essential for electrical distribution systems where space efficiency and reliable busbar mounting are critical requirements
